Description
Diablo D0654N 6-1/2″ x 54T Saw Blade for Medium Aluminum
Achieve smooth, burr-free cuts in aluminum profiles, copper piping, and brass with cordless or corded 6-1/2" circular saws. The Diablo® Steel Demon™ D0654N 6-1/2" 54-Tooth Metal Cutting Saw Blade is engineered specifically for clean slicing through medium-thickness non-ferrous metals ranging from 3/32" to 1/4", eliminating thermal distortion and secondary grinding work.
Equipped with Diablo’s specially formulated TiCo™ High-Density Carbide, this blade withstands extreme impact, heat, and tooth wear, delivering up to 50 times the cutting life of standard bonded abrasive discs. Its precision Triple Chip Grind (TCG) tooth geometry paired with a specialized kerf slices cleanly without material grab or chip welding. Finished with non-stick Perma-SHIELD® coating and laser-cut vibration stabilizer vents, it delivers whisper-quiet, dead-straight cuts across jobsite extrusions and panels.
- Engineered for Medium-Gauge Metals: Slices non-ferrous metals (aluminum, copper, brass) and plastics between 3/32" and 1/4" thickness without tearing or binding.
- TiCo™ High-Density Carbide: Formulated specifically for non-ferrous metals to deliver maximum durability and blade life.
- Laser-Cut Vibration Vents: Traps harmonic vibration and reduces chatter for cleaner edge finishes and truer tracking.
- Perma-SHIELD® Non-Stick Coating: Repels heat, gumming, and corrosion while resisting aluminum chip buildup.
- Optimized for Cordless Saws: Thin kerf profile minimizes motor drag to maximize battery runtime on 6-1/2" cordless circular saws.
Specifications
| Attribute | Specification |
| Brand / Line | Diablo® / Steel Demon™ |
| Model / Part # | D0654N |
| Diameter | 6-1/2 in (165 mm) |
| Tooth Count | 54 Teeth |
| Arbor Size | 5/8 in (includes 10 mm and 20 mm reduction bushings) |
| Tooth Grind | Triple Chip Grind (TCG) |
| Material Thickness Range | 3/32 in to 1/4 in (2.4 mm to 6.4 mm) |
| Blade Coating | Perma-SHIELD® Non-Stick |
| Maximum RPM | 9,000 RPM |
| Compatible Materials | Aluminum, Copper, Brass, Bronze, Heavy Wall Plastics |
Frequently Asked Questions
What material thicknesses can the Diablo D0654N cut?
This blade is optimized for medium-thickness non-ferrous metals with material wall thicknesses between 3/32" (2.4 mm) and 1/4" (6.4 mm). It is ideal for aluminum extrusions, channel, angle, solid bar, copper tubing, and brass.
Can this blade be used on cordless 6-1/2" circular saws?
Yes. The D0654N is engineered with a thin kerf design that draws less motor amperage, making it an excellent choice for extending battery runtime on modern 18V, 20V Max, and 54V/60V cordless circular saws.
Will this blade cut steel or stainless steel?
No. The D0654N is designed strictly for non-ferrous metals and plastics. Cutting mild steel, rebar, or stainless steel requires dedicated ferrous metal cutting blades such as Diablo’s Steel Demon Cermet II series.
Does this blade come with reducer bushings for different arbors?
Yes. The blade has a native 5/8" arbor and includes reducer bushings (such as 10 mm and 20 mm) to ensure compatibility across a wide variety of 6-1/2" corded and cordless saw brands.
