Simpson Stong-Tie STB2-75614 3/4" x 6-1/4" Strong-Tie Strong Bolt 2 Wedge Anchor, Zinc Plated

Simpson Stong-Tie STB2-75614 3/4" x 6-1/4" Strong-Tie Strong Bolt 2 Wedge Anchor, Zinc Plated:

Features:

• Part No. STB2-75614
• Chamfered top designed to prevent mushrooming during installation
• Qualified for static and seismic loading conditions (seismic design categories A through F)
• Suitable for horizontal, vertical and overhead applications
• Qualified for minimum concrete thickness of 3 1/4", and lightweight concrete-over-steel deck thickness of 2 1/2" and 3 1/4"
• Standard (ANSI) fractional sizes: fits standard fixtures and installs with common drill bit and tool sizes
• Tested per ACI355.2 and AC193

Specifications:

Model No. STB2-75614
Description: Unassembled
Coating/Material: Zinc Plated / Carbon Steel
Size:3/4 x 6 1/4
Drill Bit Diameter: 3/4
Thread Length: 3 15/16
Package Qty.: 10
