Powers 06308-PWR 1/2" Steel Drop-In Anchors
The Steel Dropin is an all-steel, machine bolt anchor available in carbon steel. Designed to be used in solid concrete, including lightweight concrete and concrete-filled steel deck members. The anchors can also be considered for hard stone and solid block base materials.
FEATURES:
- Internally threaded anchor for easy bolt removability and service work
- Flanged (lipped) version installs flush for easy inspection and standard embedment
- Smooth wall dropin can be installed flush mounted or below the base material surface (optionally available with a knurled body)
- Coil thread version accepts coil rod and typically used for concrete formwork applications
APPLICATIONS:
- Suspending Conduit
- Fire Sprinkler Supports
- Cable Trays and Strut
- Concrete Formwork
- Pipe Supports
- Suspended Lighting
APPROVALS:
- Tested in accordance with ASTM E488 in uncracked concrete
- Underwriters Laboratory (UL Listed) – File No. EX1289 and VFXT7.EX1289, see listing for sizes
- FM Approvals (Factory Mutual) – see approval for sizes
- Federal GSA Specification – meets descriptive
