Description
Irwin 1964713 18" XP600 Bar Clamp Spreader
Industrial Force Meets One-Handed Speed.
The Irwin QUICK-GRIP XP600 18-Inch Bar Clamp is built for the most demanding professional glue-ups and framing tasks. Engineered to deliver 600 lbs of sustained clamping pressure, this "Extreme Pressure" model provides the strength of a traditional bar clamp with the convenience of a one-handed trigger. Its 18-inch capacity makes it a versatile middle-ground tool for cabinetry, door assembly, and heavy-duty fabrication.
Built to resist bowing, the 1964713 features a heat-treated carbon steel I-beam bar. The tool is equipped with a Quick-Change button, allowing you to convert from a clamp to a high-powered spreader in seconds without using any additional tools. With a 3-3/4" throat depth and a full-face swivel jaw, you get even pressure distribution across your entire workpiece.
Key Performance Features:
- 600 lbs Clamping Pressure: Industrial-grade force for heavy timber, metalwork, and structural gluing.
- One-Handed Operation: Ergonomic trigger allows you to hold your workpiece with one hand and clamp with the other.
- Quick-Change Power Button: Fast, tool-free conversion between clamping and spreading modes.
- Non-Marring Swivel Jaws: Large pads protect finished surfaces and stay parallel to the workpiece under high pressure.
- Reinforced I-Beam Bar: Heat-treated steel prevents flexing even when the clamp is at its maximum 600 lb load.
- Adjustable Foot: Provides extra stability, allowing the clamp to stand upright on workbenches for easier layout.
Specifications
| Feature | Technical Detail |
| Model Number | 1964713 |
| Clamping Capacity | 18 Inches (45 cm) |
| Clamping Force | 600 lbs (272 kg) |
| Throat Depth | 3-3/4 Inches |
| Bar Type | Heat-Treated Carbon Steel I-Beam |
| Spreading Capacity | 9-1/8" – 26-7/8" |
| Jaw Design | Full-Face Swivel with Removable Pads |
Frequently Asked Questions
How does the XP600 compare to the SL300 series? +
Can the non-marring pads be replaced if they wear out? +
Is the 18-inch capacity enough for standard door framing? +
Product Specifications
category_bullets: |
600 lbs Force: Extreme pressure for heavy-duty projects. 18" Capacity: Extended reach for larger clamping tasks. One-Handed XP: Power-grip trigger for maximum leverage. |
selling_points: |
✔️ Heavy-Duty Power: 600 lbs of force for demanding jobs. ✔️ Extended Reach: 18-inch capacity for larger assemblies. ✔️ One-Handed XP: High-leverage trigger for easy pressure. ✔️ Quick-Change: Fast, tool-free spreader conversion. |
